ZYTF-MC4V

✔ Pure, bubble-free syringe filling
✔ Meets a variety of container filling syringe needs (compatible with 3.5L barrels)
✔ Compatible with syringes up to 960ml
✔ Efficient filling of high and low viscosity materials in the laboratory
✔ Transparent vacuum tube structure allows for easy visual monitoring of filling progress
✔ Single-person operation, convenient and labor-saving
✔ Stable and durable

Category:

Filling Machine

Email: sales@zyegroup.com

  • Product Description

    Model

    ZYTF-MC4V

    Operation Mode

    Manual control

    Drive Mode

    Lead screw transmission

    Power

    Manual filling force ≤ 1000 N

    Piston Specifications (mm)

    Outer diameter ≤ 130; piston stroke ≤ 135

    Applicable Cup Size (mm)

    Outer diameter ≤ 135, height ≤ 135

    Applicable Syringe

    5cc, 10cc, 30cc, 50cc
    Maximum batch size 4 at a time

    Needle Size (mm)

    Outer diameter ≤ 50

    Vacuum

    Equipped with a dual-piston vacuum pump, 8mm endotracheal tube
    Digital negative pressure gauge
    (Vacuum degree of -98KPa and above at the 0 degree altitude benchmark)
